Material:  4feet height Fence

Intermediate post

48 OD CHS (48mm OD Circular Hollow Section), 2.0mm thickness. 5ft full length, 1ft grouted, 4ft above ground. 10feet c/c. Hot dip galvanized to 90 microns. Color: BEC2CB

Strain/corner post

48 OD CHS (48mm OD Circular Hollow Section), 2.0mm thickness. 5ft full length, 1ft grouted, 4ft above ground. Only 4 corners + turn nodes. Hot dip galvanized to 90 microns. Color: BEC2CB

Post caps

48 ID female top. 1.6mm thickness. Pre-galvanized G.I profile

Strut post

33 OD CHS (33mm OD Circular Hollow Section), 2.0mm thickness. 6.5ft full length, 1.4ft inclined grouted @45⁰, 5.1ft inclined to strain post. Hot dip galvanized to 90 microns

Strut Post caps

33 ID female top. 2.0mm thickness with welded lug plate. Hot dip galvanized to 90 microns

Chain link mesh

Chain link:  2.5”, 2.5 mm wire diameter. 275GSM, 4ft height

Tension wire

4.0 mm High Tensile Wire (HT) with 275 GSM

Twist ties

Twist ties (4mm wire dia., Pre-shaped fence ties, 275 GSM)

Gate

48 mm OD steel pipe frame with 2.0 mm thickness, 3 ft span × 4 ft height, single leaf swing type, chain link mesh infill (as required), with heavy-duty steel gate posts, MS hinges (welded/bolted) and standard latch with padlock provision

Tension bars

32x5mm bar, 4 ft height, 2 XM10 apertures, hot dip galvanized to 90 microns

Center bands

25x3mm bar, 250mm pre-stressed profile, hot dip galvanized to 90 microns

Corner bands

25x3mm bar, 300mm pre-stressed profile, hot dip galvanized to 90 microns

Eye bolt

8mm, 3” length, special purposed with eye, stainless steel SS304

U clips

5mm, stainless steel SS304

O fasteners

M12 bolt, 40mm special fastener for tightening, stainless steel SS304 + nut

Fastener

M10 bolt, 40mm fastener, stainless steel SS304 + bolt

Performance Rating Overview – 4 Feet Garden Chain Link Fence

Our 4 feet garden chain link fence is designed for mini gardens, residential boundaries, landscaped areas and decorative fencing. It offers a practical combination of durability, affordability and visual appeal, making it a suitable choice for homeowners looking to define garden spaces without obstructing visibility.

Constructed using galvanized round fence posts and galvanized chain link mesh, this fencing system is intended for everyday outdoor residential applications. Below is our assessment based on five important parameters: quality, lifespan, security, economy and appearance.

Quality Rating: 4/7

The 4 feet garden fence receives a quality rating of 4/7, reflecting its dependable construction for light-duty residential applications.

The galvanized steel fence posts and galvanized chain link mesh provide resistance against rust and corrosion caused by normal outdoor exposure to sunlight, rain and moisture. The open mesh structure also allows adequate airflow and visibility while maintaining a clearly defined boundary.

This makes it a practical choice for garden fencing where moderate strength and weather resistance are the primary requirements.

Life Span Rating: 4/7

Our 4 feet garden chain link fence receives a lifespan rating of 4/7, with an expected service life of 20+ years under normal conditions, depending on material specifications, installation quality and environmental exposure.

The galvanized coating helps protect the steel components against corrosion, supporting long-term outdoor performance. Proper post installation and occasional inspection can further improve the service life of the fencing system.

It is particularly suitable for gardens and residential boundaries where the fence is not exposed to heavy physical impact or demanding security requirements.

Security Rating: 2.5/7

With a security rating of 2.5/7, this 4 feet garden fence is primarily intended for basic enclosure and boundary definition rather than high-level security.

Its relatively low height makes it suitable for:

• Defining mini garden and lawn boundaries.
• Providing basic enclosure for suitable small pets.
• Helping deter some small stray animals.
• Separating landscaped areas from surrounding spaces.

However, it is not designed to prevent human intrusion or restrict large and strong animals. For applications requiring better security, taller chain link fencing or reinforced fencing systems would be more appropriate.

Economy Rating: 5.5/7

The 4 feet garden fence scores 5.5/7 in economy, making it an affordable option for residential garden fencing.

Its lower height requires less chain link mesh and generally fewer materials than taller fencing systems. This helps reduce the overall material requirement and installation cost.

Additional advantages include straightforward installation and relatively low maintenance requirements. For homeowners looking for economical garden fencing without investing in a heavy-duty boundary system, it offers good practical value.

Beauty Rating: 4/7

The fence receives a beauty rating of 4/7, offering a neat and understated appearance suitable for residential outdoor spaces.

The galvanized chain link mesh supported by round fence posts creates a clean boundary while keeping the garden visually open. Unlike solid walls, its open mesh design allows natural light and airflow to pass through, preserving the appearance of lawns, plants and landscaped areas.

Its simple and functional design makes it suitable for homeowners who prefer an unobstructed garden view rather than a solid boundary enclosure.

Overall Assessment

The 4 feet garden chain link fence is a sensible choice for mini gardens, landscaping and residential boundaries where affordability, visibility and basic protection are the main priorities. It provides a practical balance between cost, durability and appearance, although it should not be considered a high-security fencing solution.

Frequently Asked Questions – 4 Feet CHAKRA Garden Fence

1. Do you offer a 5 feet garden chain link fence in the same design?

Yes. If you require additional height, we also offer a 5 feet domestic chain link fence in a similar design. You can explore our C5DF – 5 Feet Domestic Fence model, which provides greater boundary coverage while maintaining a similar appearance.

This option is suitable for customers who need a taller fence for residential boundaries, gardens and outdoor spaces.

2. Can I get a 2-inch chain link mesh instead of the standard 2.5-inch chain link mesh?

Yes. We can manufacture 2-inch chain link mesh instead of the standard 2.5-inch chain link mesh, depending on your requirements.

We generally recommend 2.5-inch chain link mesh because it offers a good balance between material consumption, cost and practical functionality. A smaller 2-inch chain link mesh provides closer openings and may be preferable where keeping smaller animals inside or outside the fenced area is important.

We can customize:

• Mesh opening size
• Wire thickness
• Fence height and configuration

The final price will depend on the selected specifications.

3. Can I choose angle posts instead of round poles for garden fencing?

Yes. You can choose galvanized angle fencing posts instead of round fencing poles.

However, we generally recommend round poles for this 4 feet garden fence because they are:

• More economical for this application
• Relatively lightweight
• Easier to handle and install
• Well suited for light-duty garden fencing

Both round and angle fence posts can be supplied with approximately 90-micron galvanizing, subject to the selected specification.

Angle posts have a different structural profile and may be preferable in certain installations. However, for most ordinary garden fencing applications, round fence poles offer a practical and economical solution.

4. Can I buy a garden chain link fence without accessories to reduce the cost?

Yes. You can purchase chain link mesh and posts separately or exclude selected accessories, depending on your installation requirements.

However, we recommend using the complete fencing arrangement. Components such as tension wires, bands and wire tighteners help maintain proper mesh tension, alignment and overall stability.

Without suitable tensioning arrangements, the chain link mesh may gradually become loose or sag, affecting the appearance and performance of the fence.

A complete installation is generally a better long-term investment.

5. What are the common applications of a 4 feet garden chain link fence?

A 4 feet chain link garden fence is suitable for:

• Home gardens and landscaped areas
• Lawn and garden boundaries
• Small residential plots
• Pet enclosures, depending on the animal
• Separating outdoor spaces
• Protecting plants from casual animal access

It is primarily designed for boundary demarcation and light-duty protection rather than high-security applications.

6. How long does a galvanized 4 feet chain link garden fence last?

The service life of a galvanized chain link fence depends on the quality and thickness of the zinc coating, wire specifications, installation conditions and surrounding environment.

A properly manufactured and installed galvanized fence can provide many years of service with minimal maintenance.

Coastal locations, industrial environments and areas exposed to chemicals or persistent moisture may require additional corrosion protection.

7. Is a garden 4 feet chain link fence suitable for security?

A 4 feet garden chain link fence is primarily intended for boundary marking, garden protection and basic access control.

It can help define property boundaries and discourage casual entry. However, it should not be considered a high-security fencing solution.

For greater security, we recommend considering taller fencing options, stronger posts and suitable security accessories based on the site requirements.

8. Do you provide installation support for garden chain link fencing?

We can provide installation guidance and assistance to help ensure that the fence is installed correctly.

Proper installation involves:

• Maintaining consistent post spacing
• Fixing the posts securely
• Providing adequate tension to the chain link mesh
• Installing tension wires and accessories correctly
• Maintaining a straight and uniform fence alignment

Please contact our team to discuss installation assistance for your location.

9. Do you deliver 4 feet garden chain link fencing outside India?

Yes. We cater to requirements across India and can also handle international enquiries.

For export orders, delivery arrangements, packaging, shipping terms and documentation can be discussed based on the destination country and order quantity.

Contact us with your location and approximate requirement for a quotation.

10. Can I customize the height, length and layout of the garden fence?

Yes. We can customize fencing configuration according to your site requirements.

Customization options include:

• Fence height
• Chain link mesh size
• Wire thickness
• Post type
• Post spacing
• Overall fence layout

For an accurate quotation, share your site dimensions, required fence height and preferred specifications with our team.

---

Additional FAQs worth including

11. What is the standard mesh size and wire thickness used in a 4 feet garden fence?

The standard mesh size and wire thickness depend on the selected model and application.

We offer different chain link specifications to suit residential gardens, boundary fencing and other light-duty applications. If you have a specific requirement for mesh opening or wire diameter, we can recommend a suitable configuration.

12. How far apart should the posts be installed for a 4 feet garden chain link fence?

Post spacing depends on the fencing design, mesh tension, ground conditions and site layout.

The posts must be spaced appropriately to support the tension wires and maintain a uniform fence line. For a proper quotation and installation plan, we recommend finalizing the post spacing based on the actual site conditions.

13. Is a 4 feet chain link fence suitable for keeping dogs and other pets inside a garden?

It can be suitable for certain pets, but the answer depends on the animal's size, behavior and ability to jump, climb or dig.

For smaller pets, a closer mesh opening may be preferable. If you are fencing an area for dogs, consider the dog's size and jumping ability before selecting a 4 feet fence. A taller fence or additional ground protection may be necessary in some cases.

14. Does a galvanized chain link fence require regular maintenance?

Galvanized chain link fencing generally requires relatively little maintenance.

We recommend periodically checking:

• The condition of the galvanized coating
• Post stability and ground fixing
• Tension wires and mesh tightness
• Any physical damage or loose connections

Promptly repairing damaged areas can help extend the service life of the fence.

15. How do I calculate the quantity of chain link fencing required for my garden?

To estimate the fencing quantity, measure the total boundary length of the area you want to enclose.

For example, if your garden measures 30 feet by 40 feet:

• Length: 30 feet
• Width: 40 feet
• Total perimeter: 140 running feet

You would therefore require approximately 140 running feet of fencing, with additional consideration for gates, corners, overlaps and installation requirements.

Our team can help calculate the approximate material requirement based on your site dimensions.
