Welcome to Martfury Online Shopping Store !
| Dimensions | |||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Cell size [IMPERIAL] | 2.5 inches | ||||||||||||||||||||||||
| Cell size [METRIC] | 63.5 mm | ||||||||||||||||||||||||
| Wire diameter [IMPERIAL] | 12 gauge | ||||||||||||||||||||||||
| Wire diameter [METRIC] | 2.5 mm | ||||||||||||||||||||||||
| ZINC MASS COATING AND WIRE LIFE |
275GSM & 12-20 years
|
||||||||||||||||||||||||
| Height [IMPERIAL] | 8 (6 feet | ||||||||||||||||||||||||
| Height [METRIC] | 2.4 (1.92 m chain link + 0.45m concertina coil) meters | ||||||||||||||||||||||||
| chain link tolerance | 5 % | ||||||||||||||||||||||||
| Intermediate post | 10 | ||||||||||||||||||||||||
| Strain/corner post | 10 | ||||||||||||||||||||||||
| Strut post | 12 | ||||||||||||||||||||||||
| Tension wire dia. | 4 mm | ||||||||||||||||||||||||
| concertina coil dia. | 450 mm | ||||||||||||||||||||||||
Unparalleled Security: High-Performance Barbed Wire Fencing
Elevating Perimeter Security
Explore the epitome of security with our advanced barbed wire fencing, meticulously designed to offer unmatched protection for your premises.
Specifications: Superiority Redefined
Delve into the specifications that redefine security standards:
Chain Link Cell Size [Imperial]: 2.5 inches; [Metric]: 63.5mm
Wire Diameter [Imperial]: 12g; [Metric]: 2.5mm
Zinc Mass Coating and Wire Life: 275GSM with an impressive lifespan of 12-20 years
Fence Height [Imperial]: 8 feet (Combining a 6.4-foot chain link with a 1.6-foot concertina coil); [Metric]: 2.4 meters (1.93 meters chain link + 0.45 meters concertina coil)
Chain Link Tolerance: 5%
Robust Components: A Fortress in Itself
Intermediate and Straining Posts: 48mm OD IHS, galvanized to 90 microns
Post Caps: 48mm ID, 1.6mm thickness
Tension Wire: 275GSM 4.00mm (Wire Dia.)
Concertina Coil: 450mm Dia.
Twist Ties: 275GSM 4.00mm (Wire Dia.)
Corner Bands: 300mm x 25mm x 3mm, galvanized to 90 microns
Center Bands: 250mm x 25mm x 3mm, galvanized to 90 microns
O Fasteners: M12 40mm Bolt + Nut
Fasteners: M10 12.5mm Bolt + Nut
Eye Bolt: M10 150mm Bolt + Nut
U Clips: 5mm Stainless Steel
Material: Fence
Chain link Cell size [IMPERIAL]: 2.5 inches
Chain link Cell size [METRIC}: 63.5mm
Wire diameter [IMPERIAL]: 12g
Wire diameter [METRIC]: 2.5mm
ZINC MASS OCATING AND WIRE LIFE: 275GSM and 12-15 years
Fence height [IMPERIAL]:8 feet (6’.4” chain link + 1’.6” concertina coil)
Fence height [METRIC]: 2.4 meters (1.93 meters chain link + 0.45 meters concertina coil)
Chain link tolerance: 5%
Intermediate posts: 48mm OD IHS, galvanized to 90 microns
Straining posts: 48mm OD IHS, galvanized to 90 microns
Post caps: 48mm ID, 1.6mm thickness
Tension wire: 275GSM 4.00mm (wire dia.)
Concertina coil: 450mm Dia.
Twist ties: 275GSM 4.00mm (wire dia.)
Corner bands: 300mm x 25mm x 3mm, galvanized to 90 microns
Center bands: 250mm x 25mm x 3mm, galvanized to 90 microns
O fasteners: M12 40mm bolt + nut
Fasteners: M10 12.5mm bolt + nut
Eye bolt: M10 150mm bolt + nut
U clips: 5mm S.S
“A quality product always comes with a warranty tag”
Mentioning the quality in our business process, we give a warranty for all our products. Please read the Inclusions and Exclusions in the quotation generated to check the warranty of this particular category.
WARRANTY(definition) : a written guarantee, issued to the purchaser of an article by its manufacturer, promising to repair or replace it if necessary within a specified period of time.
Question: What is GSM?
Answer: GSM is a very important factor you should be aware of when buying a galvanized iron material. GSM is the abbreviation for grams of square meter. The amount of zinc accumulated on the surface area of iron when measured in grams is zinc mass coating the wire possesses. The higher the GSM, the better is the wire quality and it’s service to you. This is often or best achieved with hot dip galvanization.
Look into our CALCULATOR to calculate the loss you might incur if you choose for a lower GSM product.
Question: What is hot dip galvanization?
Answer: Running a wire through hot tub of zinc is galvanization. Hot dip is the best method of galvanizing where the bond of zinc and iron is super strong. There are other methods of galvanizing like electro plating where zinc and iron are not well connected.
Question: Why do you have a Dollar calculation when you are based in India?
Answer: We admire your micro observation of the price. Most or many of our enquiries are generated by Indians in a foreign land for their Indian use or a foreigner seeking an Indian product. Most of the calculations are well understood when the denomination is a world standard currency which is a Dollar which many of them are accustomed to. Our presentation in Dollars allows them to study their market and analyze our quality versus price.
Question: What is the life of wire and the galvanization relationship?
Answer: This question can be answered with a simple table.
Coat grade | Galvanisation | Coastal land wire life | Dry land wire life |
Low coating | 30~40 GSM | 0~0.5years | 0~1year |
Low coating | 60~80 GSM | 1~1.5 years | 1~2 years |
Medium coating | 100~120 GSM | 6~8 years | 7~9 years |
Medium coating | 160~200 GSM | 9~12 years | 12~15 years |
Heavy coating | 275~300 GSM | 12~15 years | 15~20 years |
Question: Are poles included in this model?
Answer: When a category or design has “fence” in it’s name, it means the complete fencing along with the poles or the structure to make a complete fence. When a category or design says “chain link” or “barbed wire” it means that it does not include the poles. Kindly check the other designs also which enables you to choose which is correct for your use.
Question: I am located very far from you. How can you supply and install the fence at my site?
Answer: We have hopefully covered the entire peninsula with our supply and installation. Right from the bottom states to the north east states, we have covered the land. Your location might not surprise us for supply and installation. But also kindly observe that a few products do not include installation as they are either easy to be installed or installation might prove heavy on your spending for the fence. For such situations, we have videos which can be shared on request or we shall assist you via a video call.
Question: How do I make a quotation?
Answer: That’s easy.
1. Find “GET FREE QUOTE” under the price of product
2. Enter your details so that we know you
3. Choose the model of fencing suggested under “ Quotation required for” tab which most matches your requirement
4. Select the measurement of your boundary or requirement and enter the value in “fencing for” tab
5. Click on “SUBMIT”.
6. You will receive a OTP (one time password) to your email which shall be prompted for entry in a tab. Validate the OTP
7. The quotation will be sent to your email
8. We shall contact you soon to talk to you and execute your project
Question: I want this chain link with cement poles also. How can I get a quote for it?
Answer: We are bound to some principles where cement poles resist our reason for selling them.
1.1. Cement poles are heavier to either be transported or installed.
1.2. Cement poles are not a good investment with zero returns.
1.3. Cement poles do not give a good appeal of fencing on your property.
Considering this, we do not have cement poles in our production agenda.
However, cement or stone poles are economical which spells our justification for them. You can purchase cement or stone poles locally as there are no differentiation for stone wherever carved. We have in our list a series of genuine stone or cement pole suppliers who can be shared at your insistence. But chain link needs to be quality proved to last longer which we recommend to purchase from us.
Question: My question is unlisted in the above questions. How will you answer?
Answer: All questions either silly or serious are encouraged. Please find the contact us tab for our information and call us. We are ready for you.
Our quality assurance program is strict which pledges quality in the first place.
Our quality assurance protocol dictates
1. Plot and archive of the designs for the particular product
2. Record source of incoming material
3. In-house laboratory test for all incoming material before acceptance
4. 3 stage tests for material approval for manufacturing
5. Third party laboratory test for random samples of incoming material before acceptance
6. Die and tool checks for manufacturing
7. Scheduled manufacturing and target assigning to staff
8. Dimension test for products produced
9. Record destination of outgoing material
10. Two gate check for dispatches and quantities
11. Documentation and collection of transactions/reviews and thorough interactions with customers
With these protocols we are proud to announce, we are sure you will get the best.
